FAIRINO FR30
- Highest payload capacity in the series at 30 kg
- Robust 1403 mm reach for heavy-duty industrial tasks
- Maximum power for demanding material handling
| fitness_center | Payload | 30 kg |
| straighten | Reach | 1403 mm |
| my_location | Repeatability | ±0.1 mm |
| scale | Weight | 85 kg |
| shield | IP Rating | IP 54 |
| crop_free | Footprint | Ø 240 mm |
| 360 | Degrees of Freedom | 6 DOF |
| speed | Max TCP Speed | 2 m/s |
| bolt | Power Consumption | 600 W |
| hearing | Noise Level | max. 70 dB |
| category | Materials | Aluminum, Steel |
| inventory_2 | Availability | In Stock |
Extreme Lifting Capability
The FR30 is the heavy-lifting specialist of the Fairino range, capable of handling payloads up to 30 kg (max 35 kg). It is designed for the most demanding collaborative tasks, such as handling heavy automotive parts, large castings, or full-size shipping crates.
Payload: 30 kg
Heavy-Duty Performance
Combining a 1403 mm reach with high-speed movement (2 m/s), the FR30 delivers industrial-grade productivity. Its repeatability of ±0.1mm ensures that even the heaviest items are placed with consistent precision cycle after cycle.
TCP speed: 2 m/s
Built for the Toughest Environments
With a weight of 85 kg and a footprint of 240 mm, the FR30 is a solid, stable platform for high-torque applications. It features a typical average power consumption of 600W, providing immense capability while maintaining the ease of use and safety of a collaborative robot.
Footprint: Ø 240 mm
Applications for Fairino FR30
The applications listed below represent typical scenarios in which collaborative robots deliver long-term economic and technological value.
inventory_2Logistics, Sorting, and Packaging
Maximized Range: Extended models like the FR20 provide up to 1854 mm of reach Fast Setup: Palletizing software allows configuration in under 10 minutes without coding Dynamic Picking: Real-time conveyor tracking picks items without stopping the line Heavy Stacking: The FR30 model supports heavy-duty tasks with a 30 kg capacity | addAdvantagesremoveLimits |
Compatible accessories
| scale | Weight | 3.6 kg (without wire) |
| crop_free | Dimensions | 245 × 180 × 89 mm |
| bolt | Power Supply | 24 V / 1.5 A |
| inventory_2 | Availability | In Stock |
| scale | Weight | 2.957 kg (without wire) |
| crop_free | Dimensions | 245 × 180 × 89 mm |
| bolt | Power Supply | 24 V / 1.5 A |
| inventory_2 | Availability | In Stock |
| scale | Weight | 330 kg (excluding robot) |
| crop_free | Dimensions | 1200 × 1100 mm |
| bolt | Power Supply | 110–240 VAC |
| inventory_2 | Availability | In Stock |
