Products / Cobots / FAIRINO FR3-WMS
FAIRINO FR3-WMS
- Ideal for mobile robotics and automated guided vehicles (AGV/AMR)
- Ultra-lightweight design for maximum battery efficiency
- Optimized low power consumption for prolonged operation
| fitness_center | Payload | 3 kg |
| straighten | Reach | 622 mm |
| my_location | Repeatability | ±0.02 mm |
| scale | Weight | 10.5 kg |
| shield | IP Rating | IP 54 |
| crop_free | Footprint | Ø 128 mm |
| 360 | Degrees of Freedom | 6 DOF |
| speed | Max TCP Speed | 1 m/s |
| bolt | Power Consumption | 90 W |
| hearing | Noise Level | max. 65 dB |
| category | Materials | Aluminium, Steel |
| inventory_2 | Availability | In Stock |
Agile Design for Mobile Integration
The FR3-WMS is the ultra-lightweight evolution of the FR3 series, specifically optimized for integration with mobile platforms and AGVs. Weighing only 10.5 kg, it minimizes the load on mobile bases, allowing for longer battery life and faster transit speeds without compromising on its 3 kg payload capacity.
Weight: 10.5 kg
High Efficiency & Low Power Consumption
Built for endurance, the FR3-WMS features a typical average power consumption of only 90W. This efficiency makes it the perfect partner for autonomous mobile applications where energy management is critical, ensuring your mobile fleet stays operational for longer shifts.
Average power: 90W
Compact Precision in Motion
Despite its lightweight build, the FR3-WMS maintains a reach of 622 mm and a repeatability of ±0.02mm. Its compact 128 mm footprint and 6-DOF flexibility allow it to perform complex tasks in tight spaces, from mobile laboratory automation to dynamic warehouse picking.
Repeatability: ± 0.02 mm
Applications for Fairino FR3-WMS
The applications listed below represent typical scenarios in which collaborative robots deliver long-term economic and technological value.
factoryMaterial Production and Processing
Industrial Stability: All-metal construction handles high-torque grinding and high-heat welding Full Agility: WML variants offer 360 degree rotation on the 6th axis for complex pipes and curved surfaces Tactile Precision: Integration with 6-axis force sensors ensures constant pressure during polishing Smart Automation: Software supports real-time arc tracking and automatic weld seam recognition | addAdvantagesremoveLimits |
Compatible accessories
| scale | Weight | 3.6 kg (without wire) |
| crop_free | Dimensions | 245 × 180 × 89 mm |
| bolt | Power Supply | 24 V / 1.5 A |
| inventory_2 | Availability | In Stock |
| scale | Weight | 2.1 kg (without wire) |
| crop_free | Dimensions | 245 × 180 × 44.5 mm |
| bolt | Power Supply | 24 V / 1.5 A |
| inventory_2 | Availability | In Stock |
| crop_free | Dimensions | 1472 × 840 × 1649 mm |
| aspect_ratio | Magnetic Base Size | 382 × 331 × 121 mm |
| touch_app | Operation Methods | Web-based Teach Pendant |
| inventory_2 | Availability | In Stock |
